DC Power Supply, 24V AC, 1.5 to 14V DC, 300 mA, Track
Mfr # PSM24A24DAS
Zoro # G0394322
product price:Â
$
65.19
/ea
Key Features
Input Voltage
24V AC
Output Voltage - Nominal
1.5 to 14V DC
Current - Output
300 mA
Mounting
Track
Overall Height
4 in
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- PSM24A24DAS
- Zoro #
- G0394322
- UPC #
- -
- Country of Origin
- United States
Dimensions
- Overall Height
- 4 in
- Overall Width
- 2.75 in
- Overall Depth
- 1.63 in
- Depth
- 1-5/8 in
- Width
- 2-3/4 in
- Height
- 4 in
- Manufacturers Warranty Length
- 5 yr
Details
- Item
- DC Power Supply
- Input Voltage
- 24V AC
- Output Voltage - Nominal
- 1.5 to 14V DC
- Current - Output
- 300 mA
- Mounting
- Track
- Output Amps
- 300 mA
- Output Voltage
- 1.5 to 14V DC
- Hz
- 50/60 Hz
- Operating Temp. Range
- -30 to 140°F
- Standards
- CE, RoHS, UL
- Load Regulation
- 0.0004
- Line Regulation
- 0.625 mV/V, 8 mV/V
- Approvals
- Class 2 UL916 listed, ULC, File #E68805
- Ripple
- 0.0016%, 24 VDC @ 300 mA, 0.0016%, 24 VDC @ 1A
- DC Voltage Output Type
- Adjustable
- Input Current
- 300 mA
- Output Voltage - Maximum
- 24 V AC
Description
DC Power Supply
