HiPer-Drill Replaceable Tip Drill Insert, for Aluminum, Diameter: 13 mm
Mfr # 231630 13
Zoro # G815355484
product price: $123.99
/ea
Free Shipping & Returns
Key Features
Manufacturer Series
HiPer-Drill
Shank Type
ISO 9766
No. of Edges
2
Shank Length
50 mm
Shank Dia.
20 mm
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
231630 13
Zoro #
G815355484
UPC #
-
Country of Origin
Germany
Dimensions
Insert Size
13 mm
Shank Length
50 mm
Shank Dia.
20 mm
Overall Length
222 mm
Size
17 - 17.99 mm
Reach Length
144 mm
Details
Item
Indexable drill
Manufacturer Series
HiPer-Drill
Shank Type
ISO 9766
No. of Edges
2
Coolant Through
Yes
Clamping Screw
231999 8IP1 (1.2 Nm)
Version
8 x D
Description
Vee ground cutter inserts for precise positioning and stable seating. Concentricity when assembled 20 m. For holes up to IT9 accuracy. Note: Cutting data applies for the base body 5xD. Drill pilot holes exclusively with cutter insert of the same type. Semi-Standard: yes Point angle: 135 degrees for base body size: 13 mm Feed f in aluminium short-chipping: 0.29 mm/rev.
