Solid Carbide Torus End Mill, for Aluminum, DLC Coated, 10/1.5 mm
Mfr # 206071 10/1,5
Zoro # G414384359
product price: $195.99
/ea
Free Shipping & Returns
Key Features
Overall Length
100 mm
Milling Diameter
10 mm
Number of Flutes
2
End Mill Style
Corner Radius
Finish
DLC
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 206071 10/1,5
- Zoro #
- G414384359
- UPC #
- -
- Country of Origin
- Germany
Dimensions
- Overall Length
- 100 mm
- Milling Diameter
- 10 mm
- Length of Cut
- 11 mm
- Tolerance Nominal Diameter
- e8
- Maximum Cutting Depth Ap Max When Slot Milling From Solid
- 0.5 mm
- Maximum Cutting Depth Ap Max When Side Milling
- 11 mm
- Min. Cutting Depth
- 0.01 mm
- Shank Dia.
- 10 mm
- Neck Dia.
- 9.2 mm
- Corner Radius
- 1.5 mm
Details
- Number of Flutes
- 2
- End Mill Style
- Corner Radius
- Finish
- DLC
- Feed Fz For Copy Milling in Short-Chipping Aluminium
- 0.056 mm
- Type of Product
- Torus cutter
- Color Ring
- yellow
- Correction Factor Fz
- 1.25
- Helix Angle
- 30 Degrees
- End Mill Material
- solid carbide
- Cutting Direction
- horizontal, oblique and vertical
- Overall Reach
- 60 mm
- Shank Type
- DIN 6535 HA to h6
- Type
- W
- Coolant Through
- No
Description
With the latest generation of DLC coating sp2. With double relief ground side clearance angle and corner radius. High stability due to strengthened core. Tolerance: R1 = ±0.01 mm. No. of teeth Z: 2 Helix angle: 30 degrees Shank: DIN 6535 HA to h6 No. of teeth Z: 2 Flute length Lc: 11 mm Corner radius R1: 1.5 mm Overhang length L1 incl. recess: 60 mm Recess Dia. D1: 9.2 mm Overall length L: 100 mm
