Gast

1/Skid R6350A-2 Regenerative Blower

product price: $2,926.99
/ea
Item requires special delivery charges. A $110.00 per item surcharge will be applied.
Free 30-Day Returns

Key Features

  • Voltage 190 to 220/380 to 415V AC, 208 to 230/460V AC
  • Inlet Size 2 in
  • Outlet Size 2 in
  • Overall Length 17.43 in
  • Overall Height 15.34 in
See all product information

Product Information

Dimensions

Inlet Size 2 in
Outlet Size 2 in
Overall Length 17.43 in
Overall Height 15.34 in
Overall Depth 17.43 in
Overall Width 15.17 in

Details

Item Regenerative Blower
Voltage 190 to 220/380 to 415V AC, 208 to 230/460V AC
Phase Three
Thermal Protection No
Housing Material Aluminum
Standards CE, cURus
Sound Level 72 dBA
Frequency 50 Hz, 60 Hz
Output Power @ 50 Hz 5 hp
Maximum Operating Pressure 105 in wc
Maximum Flow Rate @ 50Hz 160 cfm
Maximum Speed 2,850 RPM, 3,450 RPM
Inlet Type NPT
Output Power 5 hp
Maximum Flow Rate 220 cfm
Wattage 3.73 kW
Outlet Type NPT
Weight 112 lb
Noise Level 72 dBA
Maximum Ambient Temperature 104 Degrees F
Maximum Vacuum 88 in wc
Maximum Flow Rate Vacuum 220 cfm @ 88 in wc
Voltage @ 50 Hz 190 to 220/380 to 415V AC
Series Gast
Duty Cycle Continuous
Outlet Gender Female
Inlet Gender Female
Maximum Air Temperature Rise 120 Degrees F
Current Rating 12.2-11.2/5.6 A
Current Rating @ 50 Hz 13 A; 6 A
Enclosure Rating NEMA 184
Enclosure Type Totally Enclosed Fan-Cooled

Description

Regenerative Blower, Phase Three, Output Power 5 hp, Maximum Operating Pressure 105 in wc, Maximum Flow Rate 220 cfm, Maximum Vacuum 88 in wc, Voltage 190 to 220/380 to 415V AC, 208 to 230/460V AC, Inlet Size 2 in, Inlet Type NPT, Inlet Gender Female, Outlet Size 2 in, Outlet Type NPT, Outlet Gender Female, Current Rating 12.2-11.2/5.6 A, Frequency 50 Hz, 60 Hz, Housing Material Aluminum
