C 4Am-70C-Cb60 Air Motor
Mfr # 4AM-70C-CB60
Zoro # G3266177
product price: $1,844.99
/ea
Free Shipping & Returns
Key Features
Motor Design
Air
Rotation
CW/CCW
Overall Length
14 15/16 in
Mount Type
Face
Length Less Shaft
6 11/16 in
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
4AM-70C-CB60
Zoro #
G3266177
UPC #
-
Country of Origin
United States
Dimensions
Overall Length
14 15/16 in
Length Less Shaft
6 11/16 in
Shaft Length
2 13/16 in
Overall Width
8 13/16 in
Overall Height
9 1/2 in
Shaft Diameter
1 1/8 in
Keyway Width
1/4 in
Keyway Depth
1/8 in
Manufacturers Warranty Length
1 yr
Keyway Length
2 3/8 in
Inlet Size
1/4 in
Description
C 4Am-70C-Cb60 Air Motor, Output Power @ Maximum Speed 0.9 hp, Maximum Torque 1,100 in-lb, No Load Speed 50 RPM, Maximum Flow Rate 72 cfm, Shaft Diameter 1 1/8 in, Shaft Length 2 13/16 in, Mount Type Face, Inlet Size 1/4 in, Air Inlet Type NPT, Rotation CW/CCW, Housing Material Cast Iron, Gear Ratio 60:1, Air Consumption 72 cfm, Housing Material Finish Painted, AGMA Gear Class Not Applicable, Air Inlet Center to Center Distance 2 1/2 in, Inlet Gender Female
