General Tools Deluxe Digital Manometer DM8200 - main

Deluxe Digital Manometer

  • Mfr # DM8200

  • Zoro # G1505621

product price: $223.99
/ea
Free Shipping & Returns

Key Features

Includes
1-year Limited Warranty, Hard Carrying Case, (2) Connection Hoses
Accuracy
+/-0.3% of Full Scale
Pressure Accuracy
+/-0.3% of Full Scale
Battery Type
9V
Pressure Resolution
0.1 psi
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
DM8200
Zoro #
G1505621
UPC #
681035412008
Country of Origin
China

Dimensions

Manufacturers Warranty Length
1 yr
For Tubing Diameter
5/32 in
Process Connection Size
5/32 in
Battery Size
9V

Details

Item
Digital Manometer
Includes
1-year Limited Warranty, Hard Carrying Case, (2) Connection Hoses
Accuracy
+/-0.3% of Full Scale
Pressure Accuracy
+/-0.3% of Full Scale
Battery Type
9V
Pressure Resolution
0.1 psi
Operating Range
0 to 2768 in wc (0 to 689 kPa)
For Use With
Computer Peripherals and Pneumatic Controls, HVACR Technicians Measuring Pressure Levels, Medical Equipment
Operating Temp. Range
32 Degrees to 122 Degrees F
Storage Temp. Range
-40 to 140F
Display
4 Digit LCD
Connection Type
(2) 0.16 in ID x 0.24 in OD x 39.37 in Hoses
Max. Pressure
100 psi
Pressure Range
0 psi to 100 psi
Calibration Certificate Included
No
Digital Display Features
4 Digit LCD
Weight
7.6 oz
Auto Power Off
Yes
Batteries Required
Yes
Process Connection Type
Hose Barb
Minimum Operating Temperature
32 Degrees F
Type of Pressure
Differential, Gauge
Minimum Pressure
0 psi
Display Units
bar, cm H2O, ft H2O, in H2O, in Hg, kg/sq cm, kPa, mbar, mm Hg, oz/sq in, psi
Data Hold
Yes
Number of Pressures Measured
Dual
Manometer Type
General Purpose Digital Manometer
Maximum Pressure
100 psi
Series
DM8200
Maximum Operating Temperature
122 Degrees F
Min/Max Capture
Yes
Operating Pressure Range
0 to 2768 in wc (0 to 689 kPa)
NIST Traceable Certificate
No
Batteries Included
Yes
Number of Connections
2
Storage Temperature Range
-4 Degrees to 140 Degrees F
Maximum Operating Pressure
100 psi
Number of Process Connections
2
Digital Display Type
Backlit LCD
Includes Data Hold
Data Hold
Pressure Stages Measured
Dual
Process Connection Material
Silicone
Includes Min/Max Capture
Min/Max Capture
Pressure Measurement - Minimum
0 psi
Data Interface
RS-232
Operating Temperature - Maximum
122 Degrees F
Includes Data Logging
No Data Logging Included
Includes Batteries
Batteries Included
Number of Digits
4
Pressure Type Measured
Differential, Gauge
Includes NIST-Traceable Calibration Certificate
No NIST-Traceable Calibration Certificate Included
Pressure Measurement - Maximum
100 psi
Operating Temperature - Minimum
32 Degrees F
Operating Pressure - Maximum
100 psi

Description

Digital Manometer, Maximum Pressure 100 psi, Minimum Pressure 0 psi, Accuracy +/-0.3 Percent of Full Scale, Process Connection Size 5/32 in, Process Connection Type Hose Barb, Batteries Included Yes, Digital Display Features 4 Digit LCD, NIST Traceable Certificate No, Series DM8200, Auto Power Off Yes, Batteries Required Yes, Battery Type 9V, Calibration Certificate Included No, Data Hold Yes, Data Interface RS-232

Restrictions

Hazardous material
