LAN Cable, White, 0.3 in Cable Dia.
Mfr # 6131787
Zoro # G310397330
original price:Â $1,113.99 , new price: $1,033.99 , 7 percent off
new price:Â $1,033.99
/ea
Free Shipping & Returns
Key Features
Standards
ANSI/TIA 568.2-D, ANSI/TIA 862, ICEA S-102-700, ICEA S-116-732, ISO/IEC 11801 ED. 2, NEC/CEC Type CMP, NEC/CEC Type CMR (UL 1666), RoHS Compliant Directive 2011/65/EU, UL 444, UL Listed CMP-LP 0.7A, UL Listed CMR-LP 0.5A
Performance Category
6
Jacket Color
White
Shielded
Shielded
NEC Article and Type
725 CL3P, 760 FPLP, 800 CMP
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 6131787
- Zoro #
- G310397330
- UPC #
- -
- Country of Origin
- United States
Dimensions
- Overall Length
- 1,000 ft
- Cable Diameter
- 0.3 in
- Wire Rope Length
- 1,000 ft
Details
- Item
- LAN Cable
- Standards
- ANSI/TIA 568.2-D, ANSI/TIA 862, ICEA S-102-700, ICEA S-116-732, ISO/IEC 11801 ED. 2, NEC/CEC Type CMP, NEC/CEC Type CMR (UL 1666), RoHS Compliant Directive 2011/65/EU, UL 444, UL Listed CMP-LP 0.7A, UL Listed CMR-LP 0.5A
- Performance Category
- 6
- Jacket Color
- White
- Shielded
- Shielded
- NEC Article and Type
- 725 CL3P, 760 FPLP, 800 CMP
- Jacket Material
- PVC
- Conductor Gauge
- 24 AWG
- Maximum Frequency
- 500 MHz
- Maximum Impedance
- 100 ohm
- Minimum Operating Temperature
- -4 Degrees F
- Resistance Properties
- Flame/Fire Retardant
- Cable Shape
- Round
- Fire Rating
- Plenum
- Maximum Operating Temperature
- 167 Degrees F
- Insulation Material
- Fluoropolymer
Description
LAN Cable, Cable Shape Round, Conductor Gauge 24 AWG, Jacket Color White, Overall Length 1,000 ft, Performance Category 6, Shielded Shielded, Fire Rating Plenum, Jacket Material PVC, Standards ANSI/TIA 568.2-D, ANSI/TIA 862, ICEA S-102-700, ICEA S-116-732, ISO/IEC 11801 ED. 2, NEC/CEC Type CMP, NEC/CEC Type CMR (UL 1666), RoHS Compliant Directive 2011/65/EU, UL 444, UL Listed CMP-LP 0.7A, UL Listed CMR-LP 0.5A, NEC Article and Type 725 CL3P, 760 FPLP, 800 CMP, End 1 Boot Type Not Applicable
