4 in. x 4 in. Spring Full Mortise 5/8 in. Radius Door Hinge with Fixed Pin - Pack of 3
Mfr # CPS4040-5/8-26D-3
Zoro # G701860702
product price:
$
27.10
/pk of 3, $9.03/ea
Key Features
Door Hinge Type
Door Hinge
Material
Steel
Finish
Chrome
Mounting
Surface Mount
Frame Leaf Width
4 in
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- CPS4040-5/8-26D-3
- Zoro #
- G701860702
- UPC #
- 704780192107
- Country of Origin
- China
Dimensions
- Frame Leaf Width
- 4 in
- Frame Leaf Height
- 4 in
- Frame Leaf Thickness
- 1/2 in
Details
- Item
- Door Hinge
- Door Hinge Type
- Door Hinge
- Material
- Steel
- Finish
- Chrome
- Mounting
- Surface Mount
- Pin Type
- Fixed Pin
Description
This model of Global Door Controls is considered as a plain bearing full mortise single acting spring hinge. It's highly recommended for use on commercial and residential door applications. Moreover, it's advised for use where automatic self closing of a door is required. The knuckle hinge is adjustable and the spring tension can be increased or decreased by using adjusting tool included. For maximum versatility use three spring hinges on required opening. Full spring tension may not be required on all hinges but allows for greater adjustment. This type sized 4 x 4 in. comes with a 5/8 in. radius in its corner, bundled with a fixed pin. Item is available in two finishes: Satin Nickel and Bright Brass.
- •Adjustable spring hinge for commercial and residential use
- •Made from solid steel for more durability and hardness
- •5/8 in. radius hinge with fixed pin - pack of 3
- •Full mortise single acting spring hinge, plain bearing
- •Recommended for use on commercial and residential door applications
- •Intended for use where automatic self closing of a door is required
- •Steel base material with fixed steel pin
- •Corner: 5/8 in. radius
- •Thickness: 0.129 in.
- •Installation: template screw hole locations
- •Easy installation
- •Packed with both wood and machine screws
- •Conforms to ANSI / BHMA - K81071F for self closing hinges
- •Meets NFPA 80 for 3 hour fire rating
- •UL Listed R19063 for “A” label fire doors
- •Brushed Chrome finish
- •Sold as a set of 3 hinges
- •1 Year mechanical and finish warranty
