  11. Plate Caster, Swivel, Polypropyln, 10 in, 2500 lb
Hamilton Plate Caster, Swivel, Polypropyln, 10 in, 2500 lb S-CH-13DB-4SL-FB - main

Plate Caster, Swivel, Polypropyln, 10 in, 2500 lb

  • Mfr # S-CH-13DB-4SL-FB

  • Zoro # G2010779

product price: $330.99
/ea
Free Shipping & Returns

Key Features

Caster Sub-Type
Swivel
System of Measurement
Inch
Wheel/Tread Material
Polyurethane
Caster Brake Type
Total Lock
Wheel Dia.
10 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
S-CH-13DB-4SL-FB
Zoro #
G2010779
UPC #
-
Country of Origin
United States

Dimensions

Wheel Dia.
10 in
Wheel Width
3 in
Mounting Height
12 1/2 in
Mounting Plate Size
5 1/4 in x 7 1/4 in
Mounting Plate Thickness
3/8 in
Mounting Bolt Dia.
1/2 in
Overall Height
12-1/2in
Stem Dia.
No Stem
Inside Slot Spacing - Width
3.375 in
Mounting Plate Width
5 1/4 in
Overall Wheel Width
3 in
Mounting Plate Length
7 1/4 in
Inside Slot Spacing - Length
5.25 in
Outside Slot Spacing - Length
6.125 in
For Axle Dia.
3/4 in
Outside Slot Spacing - Width
4.125 in

Details

Item
Plate Caster
Caster Sub-Type
Swivel
System of Measurement
Inch
Wheel/Tread Material
Polyurethane
Caster Brake Type
Total Lock
Load Rating
3000 lb
Wheel Bearing Type
Ball
Wheel/Tread Color
Green
Wheel Hardness Rating
95 Shore A
Number of Mounting Holes
4
Tread Shape
Standard
Caster Frame Material
Steel
Core Color
Gray
Non-Marking
Yes
Number of Wheels
1
Outside Bolt Hole Spacing
3-3/8 in x 5-1/4 in
Inside Bolt Hole Spacing
4-1/8 in x 6-1/8 in
Caster Plate Hole Pattern
A
Thread Guards
No
Caster Stem Type
No Stem/Plate Included
Replacement Wheel
Mfr. No. W-1030-DB-3/4
Includes
Four Position Swivel Lock
Caster Brake Included
Yes
Frame Finish
Enamel
Wheel Color
Green
Application
Automotive, Industrial
Caster Temp. Range Available
Yes
Extended Lead
No
Standards
ANSI ICWM
Swivel Construction
Kingpin
Swivel Lock Type
4-Position Directional Lock
Load Rating Range
3000 to 5999 lb
Swivel Raceway Type
Single Ball
Wheel/Tread Hardness Rating
Firm
Includes Thread Guards
No
Wheel Core Material
Iron
Wheel Type
Flat-Free
Compatible With
W-1030-DB-3/4
Load Capacity - Maximum
3,000 lb
Mounting Hole Type
Slot
Brake Location
Right Side
For Surface Type
Concrete
Mounting Plate Shape
Rectangle
Wheel Core Type
Solid
Operating Temperature - Minimum
-40 Degrees F
Operating Temperature Range
-40 Degrees to 200 Degrees F
Operating Temperature - Maximum
200 Degrees F

Description

Swivel, Plate Caster, Load Rating 3000 lb, Swivel Lock Type 4-Position Directional Lock, Wheel Dia. 10 in, Wheel Width 3 in, Wheel/Tread Material Polyurethane, Wheel Core Material Iron, Non-Marking Yes, Number of Wheels 1, Caster Brake Type Total Lock, Tread Shape Standard
