Shop HAMILTON

Plate Caster, Swivel, Polypropyln, 8 in, 1500 lb

  • Mfr # S-WH-8DB-4SL-FB
  • Zoro # G2010788
product price:
$
226.99
/ea
Free Shipping & Returns

Key Features

Caster Sub-Type
Swivel
Inside Bolt Hole Spacing
2-5/8 in x 3-5/8 in
Stem Dia.
No Stem
Non-Marking
Yes
Includes
Brake
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
S-WH-8DB-4SL-FB
Zoro #
G2010788
UPC #
-
Country of Origin
United States

Dimensions

Stem Dia.
No Stem
Wheel Dia.
8 in
Mounting Bolt Dia.
1/2 in
Wheel Width
2 in
Overall Height
9-1/2"
Mounting Height
9 1/2 in
Mounting Plate Size
4 in x 5 in
Mounting Plate Thickness
1/4 in
Inside Slot Spacing - Width
2.625 in
Inside Slot Spacing - Length
3 in
Outside Slot Spacing - Width
3 in
For Axle Dia.
1/2 in
Mounting Plate Width
4 in
Mounting Plate Length
5 in
Overall Wheel Width
2 in
Outside Slot Spacing - Length
3.625 in

Details

Caster Sub-Type
Swivel
Inside Bolt Hole Spacing
2-5/8 in x 3-5/8 in
Non-Marking
Yes
Item
Plate Caster
Includes
Brake
Extended Lead
No
Thread Guards
No
Caster Frame Material
Steel
Frame Finish
Enamel
Core Color
Gray
Application
Automotive, Industrial
Load Rating
1500 lb
Standards
ANSI ICWM
Caster Stem Type
No Stem/Plate Included
Outside Bolt Hole Spacing
3 in x 3 in
Caster Brake Included
Yes
Replacement Wheel
Mfr. No. W-820-DB-1/2
Wheel Color
Green
Caster Temp. Range Available
Yes
Number of Wheels
1
Caster Brake Type
Total Lock
Caster Plate Hole Pattern
B
System of Measurement
Inch
Wheel Core Material
Iron
Number of Mounting Holes
4
Swivel Raceway Type
Single Ball
Swivel Construction
Kingpin
Load Rating Range
1000 to 2999 lb
Includes Thread Guards
No
Wheel/Tread Hardness Rating
Firm
Tread Shape
Standard
Swivel Lock Type
4-Position Directional Lock
Wheel Bearing Type
Ball
Wheel/Tread Material
Polyurethane
Wheel/Tread Color
Green
Wheel Type
Flat-Free
Compatible With
W-820-DB-1/2
Wheel Hardness Rating
95 Shore A
Load Capacity - Maximum
1,500 lb
Mounting Plate Shape
Rectangle
For Surface Type
Concrete
Brake Location
Right Side
Mounting Hole Type
Slot
Wheel Core Type
Solid
Operating Temperature Range
-40 Degrees to 200 Degrees F
Operating Temperature - Minimum
-40 Degrees F
Operating Temperature - Maximum
200 Degrees F

Description

Swivel, Plate Caster, Load Rating 1500 lb, Swivel Lock Type 4-Position Directional Lock, Wheel Dia. 8 in, Wheel Width 2 in, Wheel/Tread Material Polyurethane, Wheel Core Material Iron, Non-Marking Yes, Number of Wheels 1, Caster Brake Type Total Lock, Tread Shape Standard
