Shop HARRINGTON

Electric Chain Hoist, 6,000 lb, 10 ft, Push Trolley, 115/230V AC, Yellow

  • Mfr # SNERP030C-10

  • Zoro # G9923234

product price:
$
6,052.99
/ea
Additional $200.00 delivery surcharge applies per item.
See details

Key Features

Color
Yellow
Electric Hoist Item
Chain Hoist
Hoist Mount
Push Trolley
Includes
Chain Container,, Push Trolley
Lift Speed
3.5 fpm
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
SNERP030C-10
Zoro #
G9923234
UPC #
-
Country of Origin
Japan

Dimensions

Housing Width
16 1/2 in
Housing Length
26 7/8 in
Manufacturers Warranty Length
1 yr
Fits Beam Height
6 in
Housing Depth
8 5/16 in
Lifting Hook Opening Width
1 11/16 in
Mfr. Warranty Length
1 yr
Maximum Lifting Length
10 ft
Body Width
16 1/2 in
Trolley Wheel Diameter
5 4/5 in
Minimum Radius Curve
66 29/32 in
For Min. Beam Flange Width
3 1/4 in
For Minimum Beam Height
6 in
Body Depth
8 5/16 in
Controller Cord Length
6 ft
Minimum Retracted Length
29 5/16 in
For Max. Beam Flange Width
6 1/32 in
Body Length
26 7/8 in

Details

Color
Yellow
Electric Hoist Item
Chain Hoist
Hoist Lift
10 ft
Hoist Mount
Push Trolley
Includes
Chain Container,, Push Trolley
Lift Speed
3.5 fpm
Load Capacity
6,000 lb
Min. Between Hooks
28 7/8 in
Motor HP
1.2 hp
Phase
1
Standards
ANSI/ASME B30.16, ASME HST-1M
Voltage
115/230V AC
Fits Brand
Harrington Hoists Inc
Reeving
2
Thermal Protection
Available Separately
Number of Speeds
1
Classification
H4
Amps @ Low Volts
23.9 A
Item
Electric Chain Hoist
Clutch
Friction Clutch
Trolley Configuration
Push Trolley
Control
110v
Control Cord
6 ft
Finish
Electrostatic Enamel
Lubrication
Oil Bath
Fits Beam Flange W
3-1/4 in to 6 in
Brake
Pull-Rotor
Features
Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake
Material
Die Cast Aluminum
Motor Horsepower
1 1/4 hp
Maximum Lifting Capacity
6,000 lb
Lifting Hook Type
Swivel Hook with Safety Latch
Current at Max. Voltage
12 A
Headroom
28 13/16 in
Number of Reeves
2
Number of Load Chains
1
Brake Type
Pull Rotor
Starts and Stops per Hour
360
Duty Classification
H4
Programmable
Non-Programmable
Pendant IP Rating
IP65
Chain Material
Alloy Steel
Body Finish
Enamel
Current at Min. Voltage
23.9 A
Lifting Hook Material
Carbon Steel
Chain Finish
Nickel Plated
Resistance Properties
Corrosion Resistant
Mount Type
Push Trolley
Clutch Type
Friction Clutch
Included Components
Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook
Fixed Lift Speed
3.5 fpm
Chain Grade
Grade 80
Body Material
Aluminum
Trolley Wheel Material
Steel
For Outdoor Use
Yes
Controls
Push Button Pendant
Includes Brake
Brake Included
Overload Protection Included
Yes
Includes Clutch
Clutch Included
Hoist IP Rating
IP55
Operating Voltage
115/230V AC

Description

Electric Chain Hoist, Duty Classification H4, Mount Type Push Trolley, Maximum Lifting Capacity 6,000 lb, Number of Speeds 1, Programmable Non-Programmable, Fixed Lift Speed 3.5 fpm, Minimum Lift Speed Not Applicable, Maximum Lift Speed Not Applicable, Trolley Speed Not Applicable, Maximum Lifting Length 10 ft, Current at Minimum Voltage 23.9 A, Current at Maximum Voltage 12 A, Motor Horsepower 1 1/4 hp, Operating Voltage 115/230V AC, Headroom 28 13/16 in, For Minimum Beam Height 6 in
