Electric Chain Hoist, 8,000 lb, 10 ft, Hook Mounted - No Trolley, 230/460V AC, Yellow

  • Mfr # NER040L-10

  • Zoro # G2373126


product price:  $10,140.99
/ea
Item requires special delivery charges. A $80.00 per item surcharge will be applied.

Key Features

Color
Yellow
Electric Hoist Item
Chain Hoist
Hoist Lift
10 ft
Hoist Mount
Hook Mounted - No Trolley
Includes
10 yr Brake Warranty, Chain Container
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
NER040L-10
Zoro #
G2373126
UPC #
-
Country of Origin
Japan

Dimensions

Manufacturers Warranty Length
10 yr Brake Warranty, 3 yr
Lifting Hook Opening Width
33 1/2 in
Maximum Lifting Length
10 ft
Minimum Retracted Length
33 1/2 in
Mfr. Warranty Length
1 yr

Details

Color
Yellow
Electric Hoist Item
Chain Hoist
Hoist Lift
10 ft
Hoist Mount
Hook Mounted - No Trolley
Includes
10 yr Brake Warranty, Chain Container
Lift Speed
11 fpm
Load Capacity
8,000 lb
Min. Between Hooks
33 1/2 in
Motor HP
4.7 hp
Phase
3
Standards
ASME B30.16, ASME HST-1M, NFPA 70, UL 1340
Voltage
230/460V AC
Classification
H4
Number of Speeds
1
Hz
60
Reeving
1
Brake
Electromagnetic
Clutch
Friction
Thermal Protection
Included
Finish
Powder Coated
Lubrication
Oil Bath
Trolley Configuration
Hook Mounted - No Trolley
Amps @ Low Volts
17.3 A
Item
Electric Chain Hoist
Starts and Stops per Hour
360
Current at Max. Voltage
17.3 A
Duty Classification
H4
Motor Horsepower
4 3/4 hp
Included Components
Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook
Body Finish
Powder Coated
Lifting Hook Type
Swivel Hook with Safety Latch
Number of Load Chains
1
Maximum Lifting Capacity
8,000 lb
Lifting Hook Material
Carbon Steel
Number of Reeves
1
Mount Type
Hook Mounted - No Trolley
Chain Finish
Powder Coated
Fixed Lift Speed
11 fpm
Headroom
33 1/2 in
Brake Type
Electromagnetic
Includes Clutch
Clutch Included
Hoist IP Rating
IP55
Clutch Type
Friction
Current at Min. Voltage
17.3 A
Includes Brake
Brake Included
Overload Protection Included
Yes
Pendant IP Rating
IP65
Programmable
Non-Programmable
Operating Voltage
230/460V AC

Description

Electric Chain Hoist, Duty Classification H4, Mount Type Hook Mounted - No Trolley, Maximum Lifting Capacity 8,000 lb, Number of Speeds 1, Programmable Non-Programmable, Fixed Lift Speed 11 fpm, Minimum Lift Speed Not Applicable, Maximum Lift Speed Not Applicable, Trolley Speed Not Applicable, Maximum Lifting Length 10 ft, Current at Minimum Voltage 17.3 A, Current at Maximum Voltage 17.3 A, Motor Horsepower 4 3/4 hp, Operating Voltage 230/460V AC, Headroom 33 1/2 in
