Harris High Purity Gas Regulator, Argon, Helium, Nitrogen, Single Stage, 1/2 in Inlet, 1/2 in Outlet KH1121 - main

High Purity Gas Regulator, Argon, Helium, Nitrogen, Single Stage, 1/2 in Inlet, 1/2 in Outlet

  • Mfr # KH1121

  • Zoro # G7130155

product price: $574.99
/ea
Free Shipping & Returns

Key Features

Compatible Gas Type
Argon, Helium, Nitrogen
Outlet Connection Size
1/2 in
Body Material
Chrome Plated Brass
Number of Stages
Single Stage
Outlet Pressure (Maximum)
250 psig
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
KH1121
Zoro #
G7130155
UPC #
725636316188
Country of Origin
United States

Dimensions

Outlet Connection Size
1/2 in
Gauge Diameter
2 1/2 in
Inlet Connection Size
1/2 in
Overall Length
5-1/2"
Body Diameter
2.75 in
Overall Width
3.22 in
Overall Depth
5.54 in
Overall Height
6.26 in
Dedupe with CGA Number and Inlet Connection Size
1/2 in NPT F

Details

Item
High Purity Gas Regulator
Compatible Gas Type
Argon, Helium, Nitrogen
Body Material
Chrome Plated Brass
Number of Stages
Single Stage
Outlet Pressure (Maximum)
250 psig
Outlet Pressure (Minimum)
0 psig
Regulator Supply Type
Pipeline
Includes
Harris Model 3530 Single Stage Regulator
Stages
Single Stage
Supply Pressure Gauge
4,000 psi
Delivery
0 to 250 psig
Gauges Delivery Pressure
400 psig
Regulator Application
High Pressure
Regulator Capacity
Heavy Duty
Application
Bulk Gas Distribution Systems, Emission Monitoring Systems Gases, High Flow, High Purity Gas Applications, Laser Gas Systems, Non-Corrosive High Flow Gas Applications, Process Analyzer Gases, Research Sample System Gases
Standards
CGA E-4
Delivery Pressure Range
0 to 250 psi
Diaphragm Material
302 Stainless Steel
Type
Single Stage
Features
Four Port Configuration, One High Pressure and Three Low Pressure, Self Reseating Internal Relief Valve
Bonnet Material
Brass
Seal Material
PTFE
Gas Purity Rating
99.999 %
Seat Material
PTFE
Inlet Connection Type
NPT
Body Finish
Chrome Plated
Outlet Thread Direction
Right Hand
Outlet Connection Type
NPT
Inlet Connection Gender
Female
Outlet Connection Gender
Female
Control Type
Knob
Inlet Pressure (Maximum)
3,000 psig
Inlet Thread Direction
Right Hand
Helium Leak Integrity Rating
1.00 x 10^-9 cc/sec
Regulator Series
HP 3530
Filter Material
Nickel Plated Bronze
Flow Coefficient
0.15

Description

High Purity Gas Regulator, Mounting Type Pipeline, Number of Stages Single Stage, Compatible Gas Type Argon, Helium, Nitrogen, Control Type Knob, Maximum Inlet Pressure 3,000 psig, Inlet Connection Size 1/2 in, Inlet Connection Gender Female, Inlet Connection Type NPT, Inlet Thread Direction Right Hand, Outlet Pressure (Maximum) 250 psig, Outlet Connection Gender Female, Outlet Connection Size 1/2 in, Outlet Connection Type NPT, Outlet Thread Direction Right Hand

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
