  9. D-Sub male solder cup 9-pole IP67, PK 100
Harting D-Sub male solder cup 9-pole IP67, PK 100 09674095615 - main

D-Sub male solder cup 9-pole IP67, PK 100

  • Mfr # 09674095615

  • Zoro # G7737420

product price: $3,350.99
/pk 100, $33.51/ea
Free Shipping & Returns

Key Features

Color
Red
Temp. Range
-25 to 70°C
Features
Turned; Straight
Termination Type
Solder Cup
Conductor Size - Data Cable
0.5 sq mm
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
09674095615
Zoro #
G7737420
UPC #
-
Country of Origin
Czechia

Dimensions

Conductor Size - Data Cable
0.5 sq mm
Size
D-Sub 1

Details

Item
Connector
Color
Red
Temp. Range
-25 to 70°C
Features
Turned; Straight
Termination Type
Solder Cup
Series
D-Sub
Standards
DIN 41652; UL 1977 ECBT2.E102079
Material
Glass Fiber Filled Thermoplastic Resin; Brass (Shell)
Number of contacts
9
Material flammability class acc. to UL 94
V-0
Test voltage U r.m.s.
1.2 kV
Element
Connector
Clearance distance
≥1 mm
Contact Resistance
≤10 mΩ
Creepage distance
≥1 mm
Degree of protection acc. to IEC 60529
IP67
Specifications
DIN 41652
Material (contacts)
Copper alloy
Performance level
1 || NM 30 (S4)
Description of the contact
Turned || Straight
UL / CSA
UL 1977 ECBT2.E102079
Identification
IP67
Rated current
5 A
Withdrawal force
≥1.8 N
Termination Method
Solder cup termination
Insulation resistance
> 5 x 10
Material (insert)
Thermoplastic resin, glass-fibre filled || Brass, tin plated
Gender
Male
Insertion force
≤30.6 N
Locking type
Fixing flange with feed through hole Ø 3.1 mm
Limiting temperature
-25 ... +70 °C
Mating cycles
≥500

Description

Connector, Solder cup termination, Rated current: ‌5 A, Male, Size: D-Sub 1, Thermoplastic resin, glass-fibre filled, Brass, tin plated, Contacts: 9, Copper alloy
