Han Hve 10 Pos. F Insert Crimp
Mfr # 09340102702
Zoro # G2046052
product price: $66.59
/eaKey Features
Color
Pebble Gray
Insulation Material
Polycarbonate
Maximum Voltage
830 V
Current
16 A
Maximum Operating Temperature
125 Degrees C
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
09340102702
Zoro #
G2046052
UPC #
-
Country of Origin
Germany
Dimensions
Max. Single Wire Size
12 AWG
Min. Single Wire Size
20 AWG
Maximum Single Wire Size
12 AWG
For Minimum Wire Size - Solid
20 AWG
Minimum Single Wire Size
20 AWG
Description
Inserts, Crimp termination, Female, Polycarbonate (PC), RAL 7032 (pebble grey), Rated current: 16 A, Size: 24 B, Contacts: 10, + 2 additional relay contacts, Conductor cross-section: 0.5 ... 4 mm2
