Flowmeter, GPM/LPM 0.2 - 2.0 / 1-7.5

HEDLAND| Zoro #: G0460932| Mfr #: H205B-020

$225.00 /ea

This item ships free. Details.Standard ground shipping.
Details:
Type: Variable Area
Flow Range: 0.2 to 2 gpm
Specific Gravity: 1.000
Save 15%. Sign up for Z-mail.

Specifications

Zoro #: G0460932 Mfr #: H205B-020
Type: Variable AreaFlow Range: 0.2 to 2 gpm
Specific Gravity: 1.000Accuracy (%): +/-7% Full Scale
Housing Material: BrassIncludes: -
Pressure Drop - 50% Flow (PSI): 6.00 psiFitting: Brass
Length: 4-13/16"Width (In.): 1-11/16"
Standards: -Flow Range @ GPM/LPM: 0.2 to 2 / 1 to 7.5
Height (In.): 1-7/8For Pipe Size: 1/4"
Max. Temp. (F): 240Application: -
Chamber Material: BrassPressure Drop - 100% Flow (PSI): 13.00 psi
Connection Size (In.): 1/4 FNPTMax. Pressure (PSI): 3500
Flow Material: Water, Other LiquidsLength (In.): 4-13/16"
Max. Viscosity: 500 SSUSeal Material: Viton
Country of Origin (subject to change): United States

Description

Flowmeter, Variable Area, Max. Pressure 3500 PSI, Connection Size (In.) 1/4 FNPT, Max. Temp. 240 F, Housing Material Brass, Chamber Material Brass, Seal Material Viton, Accuracy +/-7% Full Scale %, Flow Material Water and Other Liquids, Flow Range @ GPM/LPM 0.2 to 2 / 1 to 7.5, Pressure Drop - 100% Flow 13 PSI, Pressure Drop - 50% Flow 6 PSI, Specific Gravity 1

Restrictions and Compliance

This product is not intended for potable water applications (human consumption – drinking and cooking) and has not been designed to be compliant with the “Safe Drinking Water Act” requirements for low lead in potable water applications. This item is for use, only, in non-potable (non-human consumption) water applications.
***
This is a restricted item. It cannot be used in the USA for potable water applications.
