Flowmeter, GPM/LPM 2.0 - 20 / 10-76

HEDLAND| Zoro #: G0603486| Mfr #: H755S-020

$769.99 /ea

qty
This item ships free. Details.Standard ground shipping.
Details:
Master Totalizer:Flow Material:Thread:
Save 15%. Sign up for Z-mail.

Specifications

Zoro #: G0603486 Mfr #: H755S-020
Master Totalizer: Flow Material:
Thread: Type: Variable Area
Length: 7-3/16"Shaft Material:
Max. Pressure (PSI): 5000Pressure Drop - 100% Flow (PSI):
Gauge/Conductor: Flow Range: 2 to 20 gpm
Chamber Material: BrassStandards:
Specific Gravity: 1.000O-Ring:
GPM Max.: Display:
Fitting: Stainless SteelResetable Cumulative Totalizer:
Manufacturers Warranty Length: Max. Viscosity: 500 SSU
Depth: Pressure Drop - 50% Flow (PSI):
Seal Material: VitonAgency Compliance:
For Pipe Size: 1"Includes:
Max. Viscosity (SSU): Max. Reed Switch Current (mA):
Cable Length (Ft.): Insert:
Center-Center Insert Size: Height (In.): 2-7/8
Length (In.): Max. Voltage:
Flow Range @ GPM/LPM: 2 to 20 / 10 to 76Max. Temp. (F): 240
Temp.: Item:
Accuracy (%): +/-2% Full ScaleConnection Size (In.): 1 FNPT
Width (In.): 2-1/2"Center-Center Fitting Size:
Housing Material: Stainless steelApplication:
Country of Origin (subject to change): United States

Description

Mechanical Flowmeter, Mechanical Flowmeter, For Pipe Size 1 In., Connection Size 1 In., Connection Type FNPT, Fluid Temp. Range -20 Degrees to 240 Degrees F, Wetted Materials Brass, Max. Pressure 5000 psi, Flow Range 2 to 20 gpm, Max. Viscosity 500 SSU, Flow Material Water, Other Liquids, Variable Area, GPM Max. -, Max. Voltage -, Length 7-3/16 In., Width 2-1/2 In., Height 2-7/8 In., Housing Material Stainless Steel, Fitting Stainless Steel, Chamber Material Brass, Seal Material Viton
