07U Series - Pneumatic Rack and Pinnion Actuators, 1/4 Turn, Spring Return, ISO Mount
Mfr # 07U90SR4/ISO
Zoro # G816553056
product price: $1,152.99
/ea
Free Shipping & Returns
Key Features
Cycle Time
25 s
For Use With
One Valve 7222, 7223, 7092, 7093, 7B, 7911, 7921|Two Valves 7222, 7223, 7092, 7093, 7115, 7015
Max. Operating PSI
140 psig at 70 ºF (960 kPa at 21 ºC)
Type
90º Spring Return
Connection
1/8 Female NPT
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
07U90SR4/ISO
Zoro #
G816553056
UPC #
-
Country of Origin
United States
Details
Cycle Time
25 s
For Use With
One Valve 7222, 7223, 7092, 7093, 7B, 7911, 7921|Two Valves 7222, 7223, 7092, 7093, 7115, 7015
Max. Operating PSI
140 psig at 70 ºF (960 kPa at 21 ºC)
Type
90º Spring Return
Item
07U Series - Pneumatic Actuators
Connection
1/8 Female NPT
Temp. Range
13 to 200 ºF / -25 to 95 ºC
Description
The 07U series rack and pinion actuator uses a double piston design to generate high torque while maintaining a small envelope. The actuators are available in double acting and spring return versions for both 90 degrees and 180 degrees actuation. A position indicator provides a visual guide to the unit's position and can be removed for manual override. The high cycle life and compact size combine to support the industry trends toward automation and downsizing.
Restrictions
Hazardous material
