ER Collet Chuck, Form AD, SK 40, Projection: 70, for ER Collet: 40
Mfr # 300475 40
Zoro # G314773338
product price: $108.99
/ea
Free Shipping & Returns
Key Features
Shank Shape
AD
Projection
70 mm
Balance Quality
G 6.3 at 18,000 rpm
Spare Holex Nut No. 309580
40
Machining Strategy
HSC
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
MFR #
300475 40
Zoro #
G314773338
UPC #
-
Country of Origin
China
Dimensions
Clamping Dia.
3-26 mm
Outside Dia.
63 mm
Details
Item
Collet Chuck
Shank Shape
AD
Projection
70 mm
Balance Quality
G 6.3 at 18,000 rpm
Spare Holex Nut No. 309580
40
Machining Strategy
HSC
Balluffchip Bore
Yes
Concentricity
≤ 3 µm
Clamping Range
3 mm
Adapter
SK40
Standards
ISO 7388-1
Spare Garant High-Speed Clamping Nut No. 309610
40
Description
Taper ground internally and externally. With Balluff/RFID chip bore. HOLEX HOLEX precision clamping nut, balanced G6.3 / 18-000 rpm, all shanks fine bead blasted. Balancing quality G6.3 / 18-000 rpm. Application: For clamping tools with plain shank in collets to DIN 6499 Form A and B. Supplied with: Clamping nut. Optional extras: Pull studs PS No. 308600 308806, PS pull stud wrenches No.308820 308835, ER chuck key No. 309680 613300, ER collets No. 308901 309449, ER clamping nuts No. 309615 for sealing rings, sealing rings No. 309625 309645 for No. 309615. Machining strategy: HSC Clamping range: 3 26 mm Overhang dimension A: 70 mm External Dia D: 63 mm Spare GARANT high-speed clamping nut No. 309610: 40 Spare HOLEX nut No. 309580: 40
