External Micrometer, Disc Anvils, Non-rotating Spindle, Measuring Range: 50-75 mm
Mfr # 423005 50-75
Zoro # G414556657
product price:Â
$
489.99
/ea
Free Shipping & Returns
Key Features
Range
50-75 mm
Standards
DIN 863
Disc Anvil Dia.
19.5 mm
Scale Divisions
0.01 mm
Measurement Technology
analogue
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 423005 50-75
- Zoro #
- G414556657
- UPC #
- -
- Country of Origin
- India
Dimensions
- Disc Anvil Dia.
- 19.5 mm
- Spindle Dia.
- 8 mm
Details
- Item
- External micrometer
- Range
- 50-75 mm
- Standards
- DIN 863
- Scale Divisions
- 0.01 mm
- Measurement Technology
- analogue
- Measuring Range
- 50 mm - 75 mm
- Packaging
- sturdy box
- Micrometer Barrel Graduations
- 1/50 mm
- Spindle Pitch
- 0.5 mm
Description
With large-area, hardened disc anvils. Forged and enamelled frame. Design with non-rotating spindle. Application: For determining the tooth widths of spur and helical gears from module 0.8. Supplied with: From size 25-50 including 1 setting standard. Packaging: sturdy box
