Honeywell 3NC Safety Interlock Switch Nema 1, 4, 12, 13 IP 67 GKNA30 - main

3NC Safety Interlock Switch Nema 1, 4, 12, 13 IP 67

  • Mfr # GKNA30

  • Zoro # G4091193

product price: $139.99
/ea
Free Shipping & Returns

Key Features

Style
Multi-Entry Key Operated (Straight, 90 Degrees , or Spring Key)
Series
GKN
AC Contact Rating
10 A
DC Contact Rating
0.1 to 10 A @ 250 V
Contact Form
3NC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
GKNA30
Zoro #
G4091193
UPC #
-
Country of Origin
China

Dimensions

Height
3.54 in
Width
2.52 in
Depth
1.18 in
Conduit Size
1/2 in NPT
Overall Height
3.54 in
Overall Width
2.52 in
Overall Depth
1.18 in

Details

Item
Safety Interlock Switch
Style
Multi-Entry Key Operated (Straight, 90 Degrees , or Spring Key)
Series
GKN
AC Contact Rating
10 A
DC Contact Rating
0.1 to 10 A @ 250 V
Contact Form
3NC
Connection Type
1/2 in NPT Conduit
IP Rating
IP67
Operating Temp. Range
-13 Degrees to 185 Degrees F
Contact Material
Silver
Operating Force
5 lb
Description/Special Features
0.5 lb Extraction Force, Common Footprint Safety Switch for Multiple Applicability, Mechanical Life 500,000 Cycles, Multiple Contacts, Multiple Key and Wiring Entry Points, Shock 50G per IEC 68-2-27, Vibration 10G per 68-2-6
NEMA Rating
1, 12, 13, 4 (Indoor Only)
Standards
CCC, CE, cULus, SIL3
Body Material
Plastic
Features
Red Switch Body
Electrical Connection
1/2 in NPT Conduit
NEMA Enclosure Rating
1, 12, 13, 4, 4X
Actuator Material
Stainless Steel
Circuitry Action
Slow Action
Includes Actuating Key
No Actuating Key Included
Actuating Key Type
90 Degrees , Spring, Flat
Hazardous Location Specification
Not Rated
Operating Temperature - Maximum
158 Degrees F
Operating Temperature - Minimum
-13 Degrees F
Key Hole Location
Front, Top

Description

Safety Interlock Switch, Multi-Entry Key Operated (Straight, 90 Degrees , or Spring Key), Contact Form 3NC, Connection Type 1/2 in NPT Conduit, AC Contact Rating 10 A, Series GKN, DC Contact Rating 0.1 to 10 A @ 250 V, Solenoid Voltage Not Applicable, Height 3.54 in, Width 2.52 in, Depth 1.18 in, NEMA Rating 1, 12, 13, 4 (Indoor Only), IP Rating IP67, Operating Temp. Range -13 Degrees to 185 Degrees F, Contact Material Silver, Conduit Size 1/2 in NPT, Body Material Plastic
