Honeywell Home WiFi Thermostat, 7 Programs, 3 H, 2 C, Wall Mount, Hardwired, 20/30VAC TH8321WF1001 - main

WiFi Thermostat, 7 Programs, 3 H, 2 C, Wall Mount, Hardwired, 20/30VAC

  • Mfr # TH8321WF1001

  • Zoro # G0080565

product price: $280.99
/ea
Free Shipping & Returns

Key Features

Voltage
20/30VAC
Stages Heat
3
Mounting Type
Horizontal
Mounting Location
Wall
Color
Arctic White
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
TH8321WF1001
Zoro #
G0080565
UPC #
-
Country of Origin
Mexico

Dimensions

Height
4 15/16"
Width
1 1/8"
Depth
4 31/32 in x 4 41/64 in x 1 9/64 in
Overall Height
4 5/8 in
Overall Depth
1 1/8 in
Overall Width
4 15/16 in

Details

Item
WiFi Thermostat
Voltage
20/30VAC
Stages Heat
3
Mounting Type
Horizontal
Mounting Location
Wall
Color
Arctic White
Control Range
Heat 40 Degrees to 90 Degrees F, Cool 50 Degrees to 99 Degrees F
System Switching
Auto-Heat-Cool-Off-Emergency
Stages Cool
2
Dual Transformer Compatible
Yes
Power Method
Hardwired
750mV Compatible
Yes
Programs per Week
7
Low Battery Indicator
No
Display Type
LCD, Backlit
WiFi Capability
Yes
Green Environmental Attribute
Thermostat has Programmable Feature to Reduce Energy Consumption
Features
WiFi Able, Remote Accessible
Filter Indicator
Yes
Programmable Fan
No
Temporary Temperature Hold
Yes
Remote Sensing Capability
Yes
Display Color
Blue
Temp. Settings per Day
4
Terminal Designations
R, RC, C, W-O/B, W2-AUX/E, Y, Y2, G, A-L/A, K, U1 U1, S1 S1
Automatic Changeover
Yes
Humidification Control
Yes
Batteries Included
No
Temperature Limiting
Yes
Key Pad Lockout
Yes
Temporary Program Override
Yes
Dehumidification Control
Yes
Green Certification or Other Recognition
ENERGY STAR
Battery Backup
No
Fan Switching
Auto-On-Intermittent-Program
Standards
Energy Star
Includes
Screws, Anchors
Stages
2H/2C Conventional, 3H/3C Heat Pump
Control Type
Touch Screen
Smart Capabilities
Voice Enabled
Temperature Scale
Fahrenheit/Celsius
Number of Heating Stages - Heat Pump System
3
Backlit Screen
Yes
Number of Cooling Stages - Heat Pump System
3
Number of Heating Stages - Conventional System
2
Thermostat Type
Low Voltage
Compatible System Type
Electric Forced Air Furnaces, Gas Forced Air Furnaces, Heat Pump with Aux
Maximum Temperature Control
120 Degrees F
Google Home Compatible
No
Number of Zones
1
Amazon Alexa Compatible
Yes
Application
Heat and Cool
Minimum Temperature Control
32 Degrees F
Wi-Fi Frequency
2.4 GHz
Application/Stages
Heat and Cool; 2H/2C Conventional, 3H/3C Heat Pump
Housing Color
White
Programming Capability
5-2, 7-Day
System Settings
Auto-Cool-Emergency Heat-Heat-Off
Electrical Connection Type
Hardwired
Mounting Direction
Horizontal
Mounting Direction/Shape
Horizontal
Temperature Differential
2 Degrees F
Fan Settings
Auto-On-Circulate
Temperature Readout
Yes
Number of Cooling Stages - Conventional System
2
Compatible Software/Device
Amazon Alexa, Google Assistant, IFTTT
Temperature settings per day
4
Includes Positive Off
Yes
Temperature Control Range
40 Degrees F to 90 Degrees F
Millivolt Compatible
Yes
Shape
Rectangle
Smart Connectivity
Cellular Control, Wi-Fi Assistant Enabled, Wi-Fi Control
Filter Change Reminder
Yes
Wi-Fi Specifications
802.11b, 802.11g, 802.11n
Frequency
50 Hz, 60 Hz
Includes Batteries
No
Changeover Type
Automatic and Manual
Series
Vision Pro 8000

Description

WiFi Thermostat, Heat and Cool, Automatic and Manual, Electric Forced Air Furnaces, Gas Forced Air Furnaces, Heat Pump with Aux, Touch Screen, Dehumidification Control Yes, Digital, Dual Transformer Compatible Yes, Fan Settings Auto-On-Circulate, Humidification Control Yes, Includes Positive Off Yes, Key Pad Lockout Yes, Minimum Temperature Control 32 Degrees F, Maximum Temperature Control 120 Degrees F, Mounting Direction Horizontal, Number of Cooling Stages - Conventional System 2
