Air Pressure Switch - Adjustable, 1.5–150 mbar, CE/UL

The HONEYWELL KROMSCHRODER SW,PRESS,AIR,DL 50KG 3W is an A/C pressure switch rated for use in applications involving air and flue gas pressure measurement. It supports positive, negative, and differential pressure measurement within the specified ranges for air, flue gas, or other non-aggressive gases. The switching point is adjustable via a setting dial within the product’s specified range.

Key features include:

• Pressure range: -1.5 to 150 mbar (0.12 to 20"WC)
• Adjustable switching point with setting dial
• Tube connections; CE versions: Rp 1/4, Rp 1/8; UL versions: 1/4" NPT, 1/8" NPT
• Contact options: Silver contacts (24–250V AC, 0.05–5A), Gold contacts (5–250V AC, 0.01–5A) for CE; Silver contacts (30–240V AC, 5A), Gold contacts (max 30V AC, 0.05A) for UL
• Screw terminals with M16x1.5 cable gland or optional screw terminals with a 1/2" NPT conduit
• Certified by EU and UL; FM and AGA approved; EAC and RoHS listed
• Silicon-free construction
