Air Pressure Switch - Adjustable, 1.5–150 mbar, UL/CE

The HONEYWELL KROMSCHRODER SW,PRESS,AIR,DL 5AG 31 is an A/C pressure switch rated for use in applications involving air and flue gas pressure detection. It is compatible with positive, negative, and differential pressure measurement within specified ranges for air, flue gas, or non-aggressive gases. The device includes an adjustable switching point via setting dial as per product specifications.

Key features:

• Pressure range: -1.5 to 150 mbar (0.12 to 20"WC)
• Pneumatic connections: Tube connections; CE versions with Rp 1/4 and Rp 1/8; UL versions with 1/4" NPT and 1/8" NPT
• Contact options: Silver contacts (24–250V AC, 0.05–5A) or gold contacts (5–250V AC, 0.01–5A) for CE version; silver contacts (30–240V AC, 5A) or gold contacts (max 30V AC, 0.05A) for UL version
• Electrical connection: Screw terminals with M16x1.5 cable gland or 1/2" NPT cable conduit
• Certifications include EU certification, UL listing, FM and AGA approval
• Constructed silicon-free
