Air Pressure Switch - DL Series, Adjustable, 1.5–150 mbar

The HONEYWELL KROMSCHRODER SW,PRESS,AIR,DL 50KG 3WZ is an A/C pressure switch rated for use in applications involving air and flue gas pressure measurement. It is compatible with positive, negative, and differential pressure measurement in systems using air, flue gas, or non-aggressive gases. The device includes an adjustable switching point via a setting dial within the specified operating parameters.

Key features include:

• Pressure range: -1.5 to 150 mbar (0.12 to 20"WC)
• Pneumatic connections: Tube connections; CE versions with Rp 1/4 and Rp 1/8; UL versions with 1/4" NPT and 1/8" NPT
• Contact options: Silver contacts (24–250V AC, 0.05–5A) or gold contacts (5–250V AC, 0.01–5A) for CE version; silver contacts (30–240V AC, 5A) or gold contacts (max 30V AC, 0.05A) for UL version
• Electrical connection: Screw terminals with M16x1.5 cable gland or screw terminals with 1/2" NPT cable conduit
• Certifications: EU certified, UL listed, FM approved, AGA approved
• Construction is silicon free
