Double Solenoid Gas Valve, 3-Flange, 500 mbar, VCS7T80A05NN

The HONEYWELL KROMSCHRODER VLV ASSY, DBL SOLND, 3FLG, GAS VCS7T80A05NN is a double solenoid gas valve assembly intended for use in applications requiring automatic shut-off of gas and air. Classified as a Class A valve to EN 161 standards, it remains closed when de-energized per design specifications and operates at a maximum pressure of 500 mbar. This unit features flange connections and includes both pilot lamp indication and flow adjustment capabilities. It is certified for use in systems up to SIL 3 and PL e levels.

Key features include:

• Double solenoid design with three-flange connection
• Suitable for gas and air applications up to 500 mbar
• Remains closed when de-energized per design specifications (fail-safe operation)
• Includes pilot lamp indicator and adjustable flow control
• Rated IP65; EU certified; FM and CSA approved
• Certified for systems requiring SIL 3 or PL e
