Gas Pressure Regulator & Solenoid Valve - 1/2" DN15, 24V DC, IP65
Mfr # KS88004134
Zoro # G415399017
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAG1-/25R/NWAK is a gas valve intended for use in controlling gas pressure within specified system parameters. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), making it compatible with gas, air, and biologically produced methane as per manufacturer specifications. The device operates at a maximum inlet pressure of 500 mbar (7 psig) and features rapid actuation mechanism as described in technical documentation. It includes an integrated pilot lamp for status indication, is rated IP65 according to IEC 60529 standards for dust and water ingress protection, and is approved by FM and SA authorities.
Key features include:
- Outlet: DN 15 (1/2") Rp internal thread
- Mains voltage: 24 V DC; electrical connection via M20 cable gland on the right side of the connection box
- Outlet pressure range: 35–100 mbar
- Valve seat: reduced type
- Accessories: right-side pressure switch (30–110 mbar), test point for outlet pressure; left-side two screw plugs
- No inlet flange included
- Size designation: Size 1
- EU certified
