Gas Pressure Regulator & Solenoid Valve, 1/2" DN15, 24V DC, IP65

The HONEYWELL KROMSCHRODER VAG125/20R/NWAE is a gas valve rated for use in gas pressure regulation and control applications. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), suitable for use with gas, air, and biologically produced methane. It includes a mechanism that allows rapid actuation as specified by manufacturer parameters, an integrated pilot lamp, and is rated to IP65 ingress protection standard.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet connection: DN 15 (1/2") Rp internal thread
• Mains voltage: 24 V DC; electrical connection via M20 cable gland
• Outlet pressure range: 35–100 mbar
• Valve seat: reduced type
• Accessories include right-side pressure switch (30–110 mbar) with test point at outlet pressure; left side includes two screw plugs
• Certified to FM, SA, EU standards; size 1 configuration
• No inlet flange included
