Gas Pressure Regulator & Solenoid Valve, 1/2" DN15, 24V DC, IP65

The HONEYWELL KROMSCHRODER VAG1T-/20N/NQAA is a gas valve rated for the regulation and control of gas pressure in industrial and commercial systems. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), making it compatible with gas, air, and biologically produced methane. The device includes a mechanism that enables rapid actuation, an integrated pilot lamp, and is rated IP65 according to IEC 60529 ingress protection standards.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet connection: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• Mains voltage: 24 V DC; electrical connection via M20 cable gland on right side of connection box
• FM and SA approved; EU certified
• No inlet flange; size 1 configuration
• Valve seat reduced; includes accessories such as right-side pressure switch (30–110 mbar) with test point at outlet pressure, left-side two screw plugs
