Gas Pressure Regulator & Solenoid Valve - 1/2" DN15, 24V DC, IP65

The HONEYWELL KROMSCHRODER VAV350R/NWAK is a gas valve intended for use in controlling gas pressure within specified system parameters. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), compatible with gas, air, and biologically produced methane as specified. It incorporates a mechanism that enables rapid actuation per manufacturer specifications, an integrated pilot lamp, and is constructed to meet IP65 ingress protection standards.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet connection: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• Electrical requirements: 24 V DC; M20 cable gland connection on right side of box
• Certifications: FM, SA approved; EU certified
• Additional components: Pressure switch (30–110 mbar), test point for outlet pressure, two screw plugs on left side
• No inlet flange included; reduced valve seat design
