Gas Pressure Regulator & Solenoid Valve - 1/2" DN15, 24V DC, IP65

The HONEYWELL KROMSCHRODER VAG2-/40R/NQAE is a gas valve rated for the regulation and control of gas pressure in various systems. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), making it compatible with gas, air, and biologically produced methane. It includes rapid actuation mechanism, an integrated pilot lamp, and is constructed to meet IP65 ingress protection standards.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet connection: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• Electrical specifications: Mains voltage 24 V DC; M20 cable gland electrical connection
• Certifications: FM, SA approved; EU certified
• Additional components: Right-side mounted M20 cable gland; right-side test point for outlet pressure switch; left side includes two screw plugs
• Valve seat type: Reduced
• No inlet flange included
