Gas Pressure Regulator & Solenoid Valve, 1/2" DN15, 24V DC, IP65
Mfr # KS88019833
Zoro # G815401020
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAG1-/15R/NWSRBE is a gas valve intended for use in the regulation and control of gas pressure in industrial and commercial systems, according to manufacturer specifications. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), making it compatible with gas, air, and biologically produced methane as specified by the manufacturer. The device includes a mechanism rated for rapid actuation per product specifications, an integrated pilot lamp, and electrical connection via M20 cable gland.
Key features include:
- Maximum inlet pressure: 500 mbar (7 psig)
- Outlet: DN 15 (1/2") Rp internal thread
- Outlet pressure range: 35–100 mbar
- Valve seat: reduced
- Accessories right side: Pressure switch (30–110 mbar), test point for outlet pressure
- Accessories left side: Two screw plugs
- Size 1; no inlet flange
- IP65 rated enclosure
- FM and SA approved; EU certified
- Mains voltage: 24 V DC
