Gas Pressure Regulator & Solenoid Valve, 1/2" DN15, 24V DC, IP65

The HONEYWELL KROMSCHRODER VAH240R/NPSRAE is a gas valve rated for use in gas pressure regulation and control applications within specified parameters. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), compatible with gas, air, and biologically produced methane as per product specifications. It features rapid actuation as specified by manufacturer documentation, an integrated pilot lamp, and electrical connection via M20 cable gland.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• Valve seat: reduced
• Protection rating: IP65
• Approvals: FM and SA approved; EU certified
• Size designation: Size 1
• No inlet flange included
• Mains voltage requirement: 24 V DC
• Accessories include right-side pressure switch (30–110 mbar) with test point; left side has two screw plugs
