Gas Pressure Regulator & Solenoid Valve, 1/2" DN15, 24V DC, IP65

The HONEYWELL KROMSCHRODER VAH240R/NWAE is a gas valve rated for use in controlling gas pressure within specified system parameters. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), suitable for use with gas, air, and biologically produced methane. It features rapid actuation per manufacturer specifications, an integrated pilot lamp, and electrical connection via M20 cable gland with mains voltage at 24 V DC.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• Protection rating: IP65
• FM and SA approved; EU certified
• No inlet flange; size 1 configuration
• Valve seat reduced; right-side test point for outlet pressure switch accessory
• Includes two screw plugs as left-side accessories
