Gas Pressure Regulator & Solenoid Valve, 1/2" DN15, 24V DC, IP65

The HONEYWELL KROMSCHRODER VAG2-/40R/NQAE is a gas valve intended for use in the regulation and control of gas pressure within specified system parameters. This unit combines a Class A pressure regulator (EN 88) with a Class A solenoid valve (EN 161), suitable for use with gas, air, and biologically produced methane. It features an integrated pilot lamp and is constructed to meet IP65 standards for ingress protection.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet connection: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• Mains voltage: 24 V DC; electrical connection via M20 cable gland on right side of connection box
• Features rapid actuation mechanism as per manufacturer specifications
• FM and SA approved; EU certified
• Size 1 configuration; no inlet flange included
• Valve seat reduced design; accessories include right-side pressure switch (30–110 mbar) with test point, left-side two screw plugs
