Gas Pressure Regulator & Solenoid Valve, 500 mbar, DN15, 24V DC, IP65
Mfr # KS88016148
Zoro # G715398819
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAG1-/25R/NQAE is a gas valve intended for use in controlling gas pressure within specified system parameters. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), making it compatible with gas, air, and biologically produced methane as per product specifications. The device operates at a maximum inlet pressure of 500 mbar (7 psig) and features quick opening/closing action as per manufacturer’s design. It includes a pilot lamp that indicates operational status, is rated IP65 for ingress protection, and holds FM and SA approvals as well as EU certification.
Key features:
- Pressure regulator: Class A to EN 88 standard
- Solenoid valve: Class A to EN 161 standard; compatible with gas, air, biologically produced methane
- Maximum inlet pressure: 500 mbar (7 psig)
- Outlet connection: DN 15 (1/2") Rp internal thread; no inlet flange
- Electrical specifications: Mains voltage 24 V DC; M20 cable gland electrical connection on right side of box
- Outlet pressure range: Adjustable from 35–100 mbar
- Valve operation: Features quick opening/closing action as per manufacturer’s design; reduced valve seat design
- Accessories include right-side pressure switch (30–110 mbar) with test point at outlet pressure location; left side has two screw plugs
- Size designation: Size 1
