Gas Pressure Regulator Valve - 1/2" DN15, 24V DC, IP65, FM/SA Approved

The HONEYWELL KROMSCHRODER VAG1-/15R/NWBE is a gas valve intended for use in the regulation and control of gas pressure. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), compatible with gas, air, and biologically produced methane. It includes quick opening and closing mechanism, an integrated pilot lamp, and is constructed to meet IP65 ingress protection standards.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet connection: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• Electrical connection: M20 cable gland; mains voltage 24 V DC
• FM and SA approved; EU certified
• Size 1 configuration with no inlet flange
• Right-side accessories include a pressure switch (30–110 mbar) with test point; left side includes two screw plugs
