Gas Pressure Regulator Valve - 1/2" DN15, 24V DC, IP65, FM/SA Approved

The HONEYWELL KROMSCHRODER VAG2-/40R/NKAE is a gas valve intended for use in controlling gas pressure within specified system parameters. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), making it compatible with gas, air, and biologically produced methane as specified by manufacturer guidelines. It includes a mechanism that enables rapid valve actuation per product specifications, features an integrated pilot lamp, and is constructed to meet IP65 ingress protection standards.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet connection: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• Electrical specifications: Mains voltage 24 V DC; M20 cable gland electrical connection
• Approvals: FM and SA approved; EU certified
• Size designation: Size 1; no inlet flange included
• Accessories: Right-side pressure switch (30–110 mbar) with test point; left side includes two screw plugs
• Valve seat design is reduced type
