Gas Pressure Regulator Valve - 24V DC, DN15, IP65, Solenoid, VAG2/40R

The HONEYWELL KROMSCHRODER VAG2-/40R/NWAK is a gas valve rated for control of gas pressure within specified parameters in various systems. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), suitable for use with gas, air, and biologically produced methane. It operates at a maximum inlet pressure of 500 mbar (7 psig) and includes quick opening and closing mechanism as per manufacturer specifications.

Key features include:

• Integrated pilot lamp for operational status indication
• IP65 rated enclosure for protection against dust and water ingress
• FM and SA approvals; EU certified
• Outlet connection: DN 15 (1/2") Rp internal thread; no inlet flange
• Mains voltage: 24 V DC; electrical connection via M20 cable gland on right side of connection box
• Outlet pressure range: 35–100 mbar; reduced valve seat design
• Right-side accessory port supports a pressure switch (30–110 mbar); test point located at outlet pressure position
• Left-side accessories include two screw plugs
