Gas Pressure Regulator with Solenoid Valve, 24V DC, DN15, IP65 Rated

The HONEYWELL KROMSCHRODER VAD2-/40R/NW-50A is a pressure regulator intended for regulation and control of gas pressure in compatible systems. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), suitable for use with gas, air, and biologically produced methane. It features an outlet with DN 15 (1/2'') Rp internal thread, operates at mains voltage of 24 V DC, and includes electrical connections via M20 cable gland.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet pressure range: 35–100 mbar
• Provides rapid actuation within product specifications
• IP65 rated enclosure
• FM and SA approved; EU certified
• Integrated pilot lamp for status indication
• No inlet flange; reduced valve seat design
• Accessories include right-side pressure switch (30–110 mbar) with test point on outlet side, left-side screw plugs
