Gas Pressure Regulator with Solenoid Valve, 24V DC, DN15, IP65 Rated
Mfr # KS88003168
Zoro # G115399812
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAD120R/NW-25A is a pressure regulator intended for regulation and control of gas pressure in compatible systems. This unit integrates both a Class A pressure regulator (to EN 88) and a Class A solenoid valve (to EN 161), making it suitable for use with gas, air, and biologically produced methane as specified by manufacturer. It features an outlet with DN 15 (1/2'') Rp internal thread, operates at mains voltage of 24 V DC, and includes electrical connection via M20 cable gland. The device supports quick opening and closing functions and has an IP65 rating.
Key features:
- Maximum inlet pressure: 500 mbar (7 psig)
- Outlet pressure range: 35–100 mbar
- FM and SA approved; EU certified
- Size 1 configuration; no inlet flange
- Pilot lamp present; provides operational status information
- Valve seat: reduced type
- Accessories include right-side pressure switch (30–110 mbar) with test point on outlet side; left side fitted with two screw plugs
- Features solenoid valve with rapid actuation
