Gas Pressure Regulator with Solenoid Valve, 500 mbar, DN15, 24V DC

The HONEYWELL KROMSCHRODER VAD3T-/50N/NKGL-50A is a pressure regulator intended for regulation and control of gas pressure in compatible systems. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), suitable for use with gas, air, and biologically produced methane. It features an integrated pilot lamp for status indication and is constructed to meet IP65 ingress protection standards.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet connection: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• Provides rapid actuation functionality
• Mains voltage: 24 V DC; electrical connection via M20 cable gland on right side of connection box
• FM and SA approved; EU certified
• No inlet flange included; size 1 configuration
• Valve seat reduced; right-side accessory port supports a pressure switch (30–110 mbar) with test point at outlet, left-side includes two screw plugs
