Gas Pressure Switch - 3–500 mbar, Diaphragm, UL/CE/FM

The HONEYWELL KROMSCHRODER SW,PRESS, GAS,D17VC1 6W /B is a diaphragm gas pressure switch rated for use with positive pressure applications involving compatible gases including natural gas, biogas, air, and flue gases. It features a micro switch mechanism that utilizes a micro switch mechanism that does not contain silicone components and provides switching point adjustment through user-accessible setting dial or is available with factory-set configurations.

Key features include:

• Pressure range: 3 to 500 mbar (1.2 to 144"WC)
• Pneumatic connections: Internal Rp 1/4 (single or double), external Rp 1/8 or Rp 1/4
• Contact options: Silver contacts (24–250V AC, 0.05–5A) and gold contacts (5–250V AC, 0.01–5A) for CE version; gold contacts (max 30V AC, 0.05A) and silver contacts (30–240V AC, up to 5A) for UL versions
• Electrical connection via a four-pin plug and socket
• Certified by EU authorities; listed by UL; approved by FM and AGA; RoHS compliant
