Gas Pressure Switch - Adjustable 3–500 mbar, DG Series

The HONEYWELL KROMSCHRODER SW,PRESS,GAS,DG 110VC5 6WG is a gas pressure switch rated for monitoring positive pressure within the specified media types (gases, biogas, air, and flue gases) as per product specifications. This diaphragm-operated device features a micro switch that is constructed without intentionally added silicone materials and is intended for use with boilers or similar equipment requiring gas pressure monitoring within the specified adjustable range.

Key features include:

• Pressure range: Adjustable from 3 to 500 mbar (1.2 to 144"WC)
• Switching point adjustment via setting dial or factory set
• Pneumatic connections: Internal (1x or 2x Rp 1/4), External (Rp 1/8 or Rp 1/4)
• Contact options: Silver contacts (24–250V AC, 0.05–5A) and gold contacts (5–250V AC, 0.01–5A) for CE version; gold contacts (max. 30V AC, 0.05A) and silver contacts (30–240V AC, up to 5A) for UL versions
• Electrical connection through a four-pin plug and socket
• Certified by EU, UL listed, FM approved, AGA approved; RoHS compliant
