Gas Pressure Switch - Adjustable, DG Series, 0.4-500 mbar

The HONEYWELL KROMSCHRODER SW,PRESS,GAS,DG 50UG 3 is a gas pressure switch intended for use in applications involving positive gas and air pressures, as well as negative and differential air pressures. This device features an adjustable switching point via a setting dial and operates with media such as gas, air, and flue gases. The DG series includes both European (DG) and US (DG..T) versions, each available with various certifications and connection options.

Key features:

• Adjustable switching point using a setting dial
• Suitable for use with gas, air, and flue gases in positive pressure; air and flue gases in negative/differential pressure
• Available in European version (EU certified, AGA, EAC approved) or US version (UL Listed, FM Approved)
• Pressure range: 0.4 to 500 mbar (European), 0.2 to 200" WC (US)
• Pneumatic connections: Internal Rp 1/8", Rp 1/4" (European); Internal Rp/NPT threads available on US model
• Electrical contacts: Silver or gold contacts with various voltage/amperage ratings
• Multiple electrical connection types including screw terminals, cable glands/conduits, or plug-and-socket options
