Gas Pressure Switch, Adjustable, DG Series, 0.4-500 mbar

The HONEYWELL KROMSCHRODER SW,PRESS,GAS,DG 400B 6 is a gas pressure switch rated for use with positive gas and air pressures, as well as negative and differential air pressures. This device includes an adjustable switching point using a setting dial and operates with media such as gas, air, and flue gases. The DG series includes both European (DG) and US (DG..T) versions to accommodate different regional standards.

Key features include:

• Adjustable switching point using a setting dial
• Compatible with gas, air, and flue gases within the specified operating parameters
• Available in European (EU certified, AGA, EAC approved) or US (UL Listed, FM Approved) versions
• Pressure range: 0.4 to 500 mbar (European version), 0.2 to 200" WC (US version)
• Pneumatic connections: Internal Rp 1/8" or Rp 1/4" options available depending on the model
• Electrical contacts: Silver contacts rated up to 250V AC/5A; gold contacts available for lower voltage/current requirements
• Multiple electrical connection types including screw terminals with cable gland/conduit or plug-and-socket configuration
