Gas Pressure Switch, Adjustable, DG Series, 0.4-500 mbar

The HONEYWELL KROMSCHRODER SW,PRESS,GAS,DG 400UG 4 is a gas pressure switch rated for use with positive gas and air pressures, as well as negative and differential air pressures within specified parameters. It includes an adjustable switching point controlled by a setting dial and operates with media such as gas, air, and flue gases. The DG series includes both European (DG) and US (DG..T) versions, each with specific certifications and connection options.

Key features:

• Adjustable switching point using a setting dial
• Compatible with gas, air, or flue gases in positive pressure applications; compatible with air or flue gases in negative/differential pressure applications
• Available in European version (EU certified, AGA/EAC approved) and US version (UL Listed/FM Approved)
• Pressure range: 0.4 to 500 mbar (European), 0.2 to 200" WC (US)
• Pneumatic connections: Internal Rp 1/8", Rp 1/4" (European); Internal Rp/NPT threads (US)
• Electrical contacts: Silver or gold options with various voltage/amperage ratings
• Multiple electrical connection types including screw terminals, cable glands/conduits, plug-and-socket
