Gas Pressure Switch - Adjustable, DG Series, EU Certified

The HONEYWELL KROMSCHRODER SW,PRESS,GAS,DG 120IG 4 is a gas pressure switch rated for use in applications involving positive gas and air pressures, as well as negative and differential air pressures. This device includes an adjustable switching point controlled by a setting dial and operates with media such as gas, air, and flue gases for both positive and negative/differential pressure applications. The DG series represents the European version of this product.

Key features include:

• Includes an adjustable switching point controlled by a setting dial
• Compatible with gas, air, and flue gases within specified positive and negative/differential pressure ranges
• Available in versions certified to EU standards (DG) or US standards (DG..T)
• Electrical contacts available in silver or gold options
• Multiple pneumatic connection sizes: Internal Rp 1/8", Rp 1/4" (EU); NPT threads also available on US models
• Electrical connections via screw terminals with M16x1.5 cable gland or optional 4-pin plug/socket
