Gas Pressure Switch - Adjustable, DG Series, EU/US Versions

The HONEYWELL KROMSCHRODER SW,PRESS,GAS,DG 10U 5 is a gas pressure switch rated for use in applications involving positive, negative, or differential gas and air pressure within the specified ranges. This device features an adjustable switching point via a setting dial and operates with media such as gas, air, and flue gases for positive pressure applications, or air and flue gases for negative/differential pressure. The DG series includes both European (DG) and US (DG..T) versions to accommodate different regional standards.

Key features:

• Adjustable switching point using a setting dial
• Compatible with gas, air, and flue gases within the specified operating parameters
• Available in European (DG) version with EU certification or US (DG..T) version with UL/FM approvals
• Pressure range: 0.4 to 500 mbar (European), 0.2 to 200" WC (US)
• Pneumatic connections: Internal Rp 1/8", Rp 1/4" (European); NPT options available on US model
• Electrical contacts: Silver or gold options; multiple voltage/amperage ratings
• Electrical connection via screw terminals, cable gland/conduit, or plug/socket options
