Gas Pressure Switch - DG 360C8D, 3–500 mbar, Diaphragm Type

The HONEYWELL KROMSCHRODER SW,PRESS,GAS,DG 360C8D 5W is a gas pressure switch rated for monitoring positive pressure within the specified media types (gases, biogas, air, and flue gases) as per product specifications. This diaphragm-type switch uses a micro switch mechanism that does not contain silicone; compatible with applications involving gas pressure monitoring in accordance with manufacturer’s guidelines.

Key features include:

• Pressure range: Adjustable from 3 to 500 mbar (1.2 to 144"WC)
• Switching point adjustment via setting dial or factory set
• Pneumatic connections: Internal (1x or 2x Rp 1/4), External (Rp 1/8 or Rp 1/4)
• Electrical connection: Four-pin plug and socket
• Contact options: Silver contacts (24–250V AC, 0.05–5A) and gold contacts (5–250V AC, 0.01–5A) for CE version; gold contacts (max. 30V AC, 0.05A) and silver contacts (30–240V AC, up to 5A) for UL versions
• Certified by EU, UL listed, FM approved, AGA approved; RoHS compliant
